Tools Menu
The Tools menu provides access to the many software tools of the
AC7 to, among other things, aid in focus and exposure.
Some of the functions are explained in greater detail in later
pages, marked by the asterisk (*).
Function
Range
Description
Focus Assist
Color, Plus,
Max, Off
Color highlights your in focus
edges in the edge color of
your choice. Plus and max
Darken image and outlines
area in focus in white.
Edge Color
R,B,Y,C,M,G
Select the color of your focus
assist edge in this menu.
Peaking
On, Off
Over-sharpens the image to
give a frosted look to areas
in focus.
Exposure Assist
HML, HL
Overlays varying IRE levels in
specific colors.
1:1 Mapping*
On, Off
Maps the native signal data
to the screen of the AC7 –
one native pixel to one AC7
screen pixel, no scaling.
2X Zoom
On, Off
A 2x digital zoom feature
that allows you to get a
closer view of your image.
Aspect Scale
16:9, 4:3,
2.35:1,
1.85:1, 15:9,
16:10,
AUTO
Defines the initial scaling
parameters for the AC7.
16:9, 4:3, etc.
