PIP Menu
The AC7 allows two signals (1 HD and 1 SD) to be displayed
simultaneously using the PIP or POP function, located in this
menu.
Function
Range
Description
Multi Window
PIP, POP (Full,
4:3)
Determines the type
of windowed view.
Sub Source
Composite
Determines the
secondary source.
Position
TL, TR, BL, BR
Position of the
window.
Size
Small, Medium,
Large
Determines the size of
the window.
Border
Black, Blue
Border or no border.
Swap
Swap
Swaps the two signals
