28 | P a g e
1:1 Mapping
When activated, each native pixel of the input signal is mapped to
a native pixel on the display. This is also called “Pixel to Pixel”.
When viewing HD signals (720p and up), only a portion of the
image will be displayed on the AC7 as 1:1 Mapping essentially
performs a "zooming" effect on the native HD image
To move the viewable window around:
When 1:1 is activated and no menu is being displayed:
1 – Roll the scroll wheel to the left
2 – Now roll the wheel in either direction to move the window
around
3 – Press button B to change the direction of movement
4 – Press the back button (Button A) to exit this dialog
