Ground
Connect to Control Panel
Make sure the control panel is in pairing state, trigger the detector
to alarm until the panel gives out a beep, which indicates the
connection succeeded. Arm the system, trigger the detector
again, and the siren of control panel will hoot to conrm that the
connection is successful.
Specications
Power supply:
18650 3.7 V 1800 mAh rechargeable lithium battery
Standby current: < 0.16 mA
Solar panel output current: 2000LX illumination ≥ 4 mA
Battery standby time: <180 days
Detection scope: 8 m/110°
Wireless transmitting distance: < 80 m (in open area)
Radio frequency: 868 MHz or 915 MHz
Operating condition:
Temperature: -10°C ~ + 55°C
Relative humidity: < 80% (non-condensing)
Housing material: PC+ABS+ANTI-UV
Detector dimensions (L x W x H): 186 x 200 x 125 mm
Bracket dimensions (L x W x H): 75 x 72 x 155 mm
