6. Preparing the installation
The first step is to prepare the physical installation of the EV Wall as described in this chapter.
Installation prerequisites
Calculate the existing electrical load to find the maximum operating current for the charging
station installation. The Smappee EV Wall is equipped with 1 connector (socket or fixed cable)
which needs to be powered.
Obtain all necessary permits from the relevant local authority.
Refer to local wiring regulations to select the conductor sizes and use only copper conductors.
Make sure that the installation area of the charging station is adequate for usability and
ventilation purposes.
Use the correct tools and provide sufficient material resources and protection measures.
Power supply
The appropriate wire gauge of the supply cable depends on the power rating and distance
between the meter cabinet and the charging station. The voltage drop must not exceed 5%. It
is advisable to have a maximum voltage drop of 3 %.
The maximum wire gauge that can be fitted is 6 mm² in case of flexible conductors or 10 mm²
when solid conductors are used.
The power supply trajectory from the circuit breaker panel up to the EV Wall Business
charging station must be protected against short-circuiting and over-current with B or C circuit
breakers (or otherwise in compliance with local standards and regulations)
A charging station connector must always be installed on a dedicated power circuit.
When the power supply and the charging station are part of a TN-S system, the station must
be grounded via the main distributor.
Route the power supply cables to the position where the charging station will be installed
together with an Ethernet cable for the internet connection (if applicable).
Make sure that there is at least 30 cm cable available at the location of the EV Wall to be able
to connect it easily internally.
Local regulations may be applicable and can vary depending upon the region or country.
The power supply enters the station at the bottom of the housing through the middle
cable gland.
The Cat 5/6 communication cable also enters the charging station via the floor plate.
Ensure that you attach the RJ-45 connector only after inserting the cable into the EV Wall
housing.
