3. Other Items
Low battery alarm and replacement of battery
1). While using the unit, if battery voltage is lower than
7.2V+-0.2 V, in the LCD display will be shown as a
symbol , that indicates the unit is in low battery
and can not work properly, please replace the battery
at once.
2). Replacement of battery:
uncover the unit back plank, open the battery door,
take out the old 9 V battery, make change new battery.
(Notice the battery polarity), then close the battery
door, shown as following figure:
I n t r o d u c t i o n
This product adopts ultrasonic principle to take meas-
urement of cable height. When taking measurement, the
unit transmits an ultrasonic signal by a 15 angle to tow-
ards the wires and measuring the time it takes to pick up
the echo from the signal.
This unit takes conveniently, operates easily, circuit
maintainer can make measurement of cable height and
wire to wire distance at any time anywhere, which not
need to get in touch with electric (communicating) high
cable.
F e a t u r e s a n d F u n c t i o n s
NOTES:
9V battery
For measuring the height up to 6 cables together.
Convenient to take measurement, easy to aim at the
measuring position and to read measuring results.
For measuring the distance between wire and wire.
Be applicable to different use of cables.
Uses large measuring sensor, higher accuracy than
existing cable height meter in market.
Compact and easy to take along.
For measuring dimension of house and distance
between objects.
The temperature compensation function enables the
Remove the battery from the unit if it is not required
for extended periods of time in order to avoid damage
to the battery life from a leaking battery.
Dispose of battery should in accordance with local
laws and regulations.
unit compensates error automatically under the temp-
erature of -10 +40 , and ensures the measuring
accuracy on different temperature conditions.
