9!8 Helpful hints
Fuses
35 Engine control unit 7.5 A Brown
36 Reversing light 7.5 A Brown
37 Rear window heater 30 A Green
38 Seat heater* 30 A Green
39 ! ! !
40 Heater blower 30 A Green
41 Ignition/starter switch 40 A Orange
42 Power windows 40 A Orange
43 Cooling blower (coolant fan in engine compartment) 40 A Orange
44 ECU AMT control unit, automated manual transmission 40 A Orange
No. Consumers Amperage Colour
!"#$%&$%'&#())*#+#,-.))/-0123456-789:%%;##<=4>=#K##@4>>A%B6C#DE9#FG1'G&#D)).##/H*?#)/
