Helpful hints 9!13
Replacing the bulbs
Changing rear lights
! Open the tailgate.
! Release the two Phillips!head screws
on either side of the bulb housing.
! Fold the housing to one side and pull it
off to the rear.
! Pull off the central plug (A).
! The bulb holder is secured by eight
tongues. Unclip these.
! Press and turn the faulty bulb to the
left to remove.
! Twist in the new bulb.
! Reconnect the central plug.
! Press the two ball guides (A) back into
the plastic holders, taking note of the
upper guide pin (B).
! Insert the bulb housing.
! Tighten the Phillips!head screws
again.
