MATRIX SPECIFICATIONS
Video
Bandwidth 400 MHz
Input Signal Level 1 Volt pk-pk into 75R
Output Impedance 100 Ohms
Input Impedance 75 Ohms
Connector 16 x HD15 socket female
Format VGA/SVGA/XGA/RGBHV/RGsB/
CVBS/YC/YUV/RGBS
Syncs TTL5VDC
Bandwidth Horizontal Sync up to 85KHz
RS-232 16 x RS232 DB9 Female, TX, RX, GND
Infrared 16 x IR 3.5mm Jack to IR emitter
Front Panel 16 x RJ45 with video, audio and data modulated within single UTP
Audio
Signal 15KHz 0dB unbalanced 100 Ohms
impedance
Connector RCA or 3.5 Stereo Jack
Control
IR 3.5mm connector with 38khz
DB9 female RS232 or RS422 @ 9600bps
Dimensions
Height X width X Depth 3U (88mm) x 19” x 450mm
Weight 9 lbs.
