Smartgen ACC4100 User Manual

ACC4100 Diesel Air Compressor Controller User Manual Page 31 of 52
No.
Type
Function Description
47
Battery Undervolt
Act when battery voltage low warning occurs.
48
Failed to Charge
Act when failed to charge warning occurs.
49
Reserved
50
ECU Warning
ECU issued a warning alarm signal.
51
ECU Shutdown
ECU issued a shutdown alarm signal.
52
ECU Comm. Failure
Controller cannot communicate with ECU.
53
Reserved
54
NCD Lamp Output
DPF regeneration related lamp outputs of Euro V engine.
55
Regen Req Lamp
56
Regen Inhibit Lamp
57
Discharge Temp Lamp
58
Regen Response Lamp
59
Input 1 Active
Act when input port 1 is active.
60
Input 2 Active
Act when input port 2 is active.
61
Input 3 Active
Act when input port 3 is active.
62
Input 4 Active
Act when input port 4 is active.
63
Input 5 Active
Act when input port 5 is active.
64
Reserved
65
Reserved
66
Reserved
67
Emergency Stop
Act when emergency stop alarm occurs.
68
Failed to Start
Act when failed to start alarm occurs.
69
Failed to Stop
Act when failed to stop alarm occurs.
70
Under Speed Warn
Act when engine under speed warning occurs.
71
Under Speed Shutdown
Act when engine under speed shutdown occurs.
72
Over Speed Warn
Act when engine over speed warning occurs.
73
Over Speed Shutdown
Act when engine over speed shutdown occurs.
74
Reserved
75
Reserved
76
Load Control 1
When “Alt Config. 1 Active” is active, under normal running state,
load control 1 outputs.
77
Load Control 2
When “Alt Config. 2 Active” is active, under normal running state,
load control 2 outputs.
78
Load Control 3
When “Alt Config. 3 Active” is active, under normal running state,
load control 3 outputs.
79
High Temp Warning
Act when high temp. warning alarm occurs.
80
Low Temp Warning
Act when low temp. warning alarm occurs.
81
High Temp Shutdown
Act when high temp. shutdown alarm occurs.
82
Reserved
83
Engine Low OP Warn
Act when low oil pressure warning occurs.
84
Engine Low OP Shut
Act when low oil pressure shutdown occurs.
85
Reserved
86
Reserved
87
Reserved
