Smartgen APC715 User Manual

APC715 Pump Unit Controller
APC715 Pump Unit Controller ISSUE 2013-08-28 Version 1.0 Page 52 of 62
12.3 CUMMINS QSM11(IMPORT)
It is suitable for CM570 engine control module. Engine type is QSM11 G1, QSM11 G2.
Terminals of controller
C1 connector
Remark
Fuel relay output
5&8
Outside expand relay, when
fuel output, making port 5 and
port 8 of C1 be connected
Start relay output
-
Connect to starter coil directly
Terminals of controller
3 pins data link connector
Remark
CAN GND
C
CAN communication shielding
line(connect with ECU
terminal only)
CAN(H)
A
Impedance 120Ω connecting
line is recommended.
CAN(L)
B
Impedance 120Ω connecting
line is recommended.
Engine type: Cummins ISB
12.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Terminals of controller
50 pins connector
Remark
Fuel relay output
38
Oil spout switch
Start relay output
-
Connect to starter coil directly
Terminals of controller
9 pins connector
Remark
CAN GND
SAE J1939 shield-E
CAN communication shielding
line(connect with ECU
terminal only)
CAN(H)
SAE J1939 signal-C
Impedance 120Ω connecting
line is recommended.
CAN(L)
SAE J1939 return-D
Impedance 120Ω connecting
line is recommended.
Engine type: Cummins QSX15-CM570
