Smartgen HGM6120N

HGM6100N Series Genset Controller User Manual Page 20 of 47
No.
Items
Range
Default
Description
18(13)
Wait for Stop Time
(0-120)s
0
If “ETS Solenoid Hold” set as 0, it is the time
from end of idle delay to genset at rest; if not
0, it is from end of ETS solenoid delay to
genset at rest.
19(14)
Switch Close Delay
(0.0-10.0)s
5.0
Mains’ or generator’s switch closing pulse
width, when it is 0, output is continuous.
20(15)
Flywheel Teeth
(10.0-300.0)
118
Number of flywheel teeth, it can detect
disconnection conditions and engine speed.
21(16)
Gen Abnormal Delay
(0-20.0)s
10.0
Over or under voltage alarm delay.
22(17)
Gen Over Voltage
Shutdown
(30-60000)V
264
When genset voltage is over the point,
generator over voltage is active. When the
point is 60000V, generator over voltage is
disabled.
23(18)
Gen Under Voltage
Shutdown
(30-60000)V
196
When generator voltage is under the point,
generator under voltage is active. When the
point is 30V, generator under voltage is
disabled.
24(19)
Under Speed
Shutdown
(0-6000)r/min
1200
When the engine speed is under the point for
10s, shutdown alarm signal is sent.
25(20)
Over Speed
Shutdown
(0-6000)r/min
1710
When the engine speed is over the point for
2s, shutdown alarm signal is sent.
26(21)
Gen Under Frequency
Shutdown
(0-75.0)Hz
45.0
When generator frequency is lower than the
point (not equal to 0) for 10s, shutdown alarm
signal is sent.
27(22)
Gen Over Frequency
Shutdown
(0-75.0)Hz
57.0
When generator’s frequency is over the point
and continues for 2s, generator over
frequency is active.
28(23)
High Temperature
Shutdown
(80-300)ºC
98
When the temperature sensor value is over
this point, it sends out high temp. alarm.
When the value is 300, warning alarm won’t
be sent. (only suited for temperature sensor,
except for high temp. pressure alarm signal
inputted by programmable input port.)
29(24)
Low Oil Pressure
Shutdown
(0-400)kPa
103
When the oil pressure sensor value is under
this point, Low Oil Pressure alarm is sending
out. When the value is 0, warning alarm won’t
be sent. (only suited for oil pressure sensor,
except for low oil pressure alarm signal
inputted by programmable input port.)
30(25)
Low Fuel Level
Warning Value
(0-100)%
10
When fuel level sensor value is under this
point and remains for 10s, genset sends out
warning alarm, only warn but not shutdown.
