Specifications
• Load types: Permanently installed incandescent and inductive loads
• Operation: Dimming Triac (12-amp Rated)
• Maximum load: (2380) 600 watts / (2381) 1,000 watts
• Input power: 120 VAC, 60 Hz
• Connections (16 AWG): Black (to line), Red (to load), White (to neutral, required)
Yellow (to optional Multi-way Companion Switches, 2382)
• Addresses: 1 PLC (X-10) Base (Primary) Address of 256 possible
Up to 64 PLC (X-10) Scene Addresses of 255 possible
• On-Level: (Primary Address) 1 of 31 possible (3.2%-100%) or resume dim
(Scene Address) 1 of 32 possible (0%-100%)
• Fade-on Rate: 0.12 to 9 seconds if programmed locally
0.12 sec. to 9 minutes if programmed remotely
• SwitchLinc Dimmers
per gang box (max): 4
• SwitchLinc Dimmers 10 (with more than 5, a PLC amplified
maximum per circuit: coupler-repeater is highly recommended)
• Minimum load: No minimum load required
• Operating temperature range: 40
O
F to 104
O
F
• Minimum PLC transmit level: 2V
• Minimum PLC receive level: 10mV
• Maximum PLC signal rejection: 200mV
• Mounting: Mounts in single or multiple-ganged J-box (200W of load control
is lost on 600W SwitchLinc for each immediately adjacent dim-
mer installation; e.g., 600W load control becomes 400W with a
SwitchLinc to the immediate right or left. Use a triple-gang box
with a mechanical switch in the center to avoid downgrading.
• Status indicator: Green LED
• Brightness indicator: 8 Green LEDs
• Dimensions - (2381) Front Bracket Main Body
(Width) 2.36” 1.74”
(Height) 4.14” 2.71”
(Depth) 1.73” 1.40”
(2380 & 2382) Front Bracket Main Body
(Width) 1.73” 1.74”
(Height) 4.14” 2.71”
(Depth) 1.73” 1.40”
• Safety tested for use in the U.S. and Canada
Invest in Better Home
Automation Products
Unlike most electric items, many PLC-based
products haven't changed much over the
years.
Our Marketing and Customer Service teams surveyed our customers,
like you, and our engineers have invented new and better wall switch-
es and plug-in modules. We include more features, higher load han-
dling, and better signal sensitivity for a superior user experience.
While in some cases, they cost more; we hope you'll agree that not
having to replace a dead module every couple years is worth the
added expense and reduced aggravation. Please visit a retailer or
distributor for the complete line of automation products from
Smarthome Design. Check out our web site at:
http://www.smarthome.com/smarthomedesignstore.html
KeypadLinc 6 with
450W integrated
dimmer
15
