5. Seat
Release the seat post clamp lever and set the
seat post height to the position which is suitable
for you to comfortably reach the ground when you
are sitting on the bike, then refasten the seat post
clamp. The maximum height should be within the
max height markings on the seatpost.
6. Pedals
Attach the pedals to the cranks, paying attention
to the “L” or “R” marked on the pedal axles. Note:
the pedals have opposing threads – screw in the left
pedal counterclockwise and screw in the right pedal
clockwise. Install L pedal counterclockwise and the
right pedal clockwise.
2. Assembly Instructions
3. Mudguard
Install the front mudguard and front light on the
fork. Take off the bolt from the front fork, put the
front mudguard hanger mount on the inside or
outside of the fork then put the front light bracket
on. Put the bolt through the fork then fasten the
bolt with a 5mm allen key and 10mm spanner.
Then fasten the two mudguard stays to the forks.
Finally connect the light cable to the front light.
4. Power Connection
Finally connect the main cable exciting the frame
near the headtube to the handlebar components
cable, making sure the arrows align before pushing
the connectors together.
2. Assembly Instructions
eCity & eUrban eCity & eUrban
