GATEWAY USER MANUAL

For all Broadcom chipset-based models including:

ADSL 3xx series: SR300n, SR350n, SR360n

VDSL 5xx series: SR500n, SR505n, SR510n, SR550n, SR552n

Release 3.0

June, 2014

Table of Contents

Other manuals for SmartRG 505N Series

Quick Start Guide12 pages

Installation Guide8 pages

Questions and Answers

R
ryandawnAug 10, 2025
How to access system logs on SmartRG 505N?
- D
  Donald RodriguezAug 10, 2025
  To access system logs on your SmartRG Gateway: 1. Select 'Management' -> 'System Log'. 2. Click 'Configure System Log'. 3. Choose the 'Log Level' from the dropdown list; 'Debugging' offers the most detailed log information. 4. Select the 'Display Level' from the dropdown; 'Debugging' provides the greatest level of display detail. 5. Click 'Apply/Save'. 6. To configure the remote 'Mode' select 'Remote' from the drop down list and configure the remote server’s IP address and UDP port number.
J
Joe PollardAug 25, 2025
What to do if I want to monitor traffic on the WAN interface (Port Mirroring) of SmartRG 505N Gateway?
- E
  Eric ReedAug 26, 2025
  To monitor traffic on the WAN interface (Port Mirroring) of your SmartRG Gateway: 1. Enter the URL for the 'Port Mirroring' hidden page into your browser: /admin/engdebug.cmd. 2. Click the 'Enable' check box. 3. Select the target LAN port from the 'Mirror Interface' dropdown box. 4. Click 'Apply/Save'.

SmartRG 505N Series Specifications

General

Ethernet Ports	4
Firewall	Yes
QoS	Yes
Device Type	Gateway
Wireless Frequency Bands	2.4 GHz
Security Protocols	WPA, WPA2
