4. Connection to mains adapter
Following proper mounting of the smaXtec Repeater please connect the mains
adapter. Please follow the steps below:
• Connect the power supply provided to the smaXtec Repeater and plug in. If
there is no plug socket within 3 m/10 ft then it is best to install a new one to
the left of the smaXtec Repeater.
• Please note:
o It is not permitted to loop cables around the smaXtec Repeater
(transmission problems).
o If possible, the cable should lead to the smaXtec Repeater from above
5. Verification of correct functionality with the help of status LEDs
Following successful completion of all steps, the status of the smaXtec Repeater can
be verified with the help of the LEDs. As soon as the mains adapter is connected the
smaXtec Repeater starts up. Following successful installation, please check the
status of the LEDs:
• smaXtec Repeater has started up: Power LED glows steady green
• connected to the smaXtec Base Station: Link LED glows steady green
The LEDs in detail:
Power LED:
• Glowing green: Started up/OK
• Flashing red/red: Error
Link LED:
• Flashing yellow: Connecting
• Glowing green: Connected to the smaXtec Base Station (either direct or via a
smaXtec Repeater)
• Flashing red/red: No connection to the smaXtec Base Station (either direct or
via other smaXtec Repeaters)
Data LED:
• Flashing green: Data being read out from smaXtec Sensors
