-106-

No. DOC1045423

• Writing service data

(1) Access the CoE object by referring to “Read/write CoE object” (page 89)

(2) Enter the following value in the parameter 4009:0 Device read/write of unit 0 EX600-LAB1.

When setting “CoL (Selection of display color)” to “0x01: Grn (Constantly green)”

CoE object

Setting value

4009:02

Port

Port 1

4009:03

Index

0x03EA

4009:04

SubIndex

0x00

4009:05

Length

0x01

4009:06

Data

0x01

(3) Double-click 4029:01 Request, select Write for Enum, and press the OK button to execute the write.
