■Details of the Diagnostic Data
•SI unit (ITV)

1
Index
1
Name (Meaning)
Type
Value
50x0:0
Short circuit
UNSIGNED8
Number of Channels
50x0:01
:
50x0:04
ITV 1
:
ITV 4
Enum081C
0 = No error
1 = Error
50x1:0
ITV connection
UNSIGNED8
Number of Channels
50x1:01
:
50x1:04
ITV 1
:
ITV 4
Enum0820
0 = ITV disconnected
1 = ITV connected
50x2:0
ITV error
2
UNSIGNED8
Number of Channels
50x2:01
:
50x2:04
ITV 1
:
ITV 4
Enum081C
0 = No error
1 = Error
50x3:0
Accumulated energizing time (hour)
UNSIGNED8
Number of Channels
50x2:01
:
50x2:04
ITV 1
:
ITV 4
UNSIGNED32
0 to 0xFFFFFFFF
1: If the “SI unit data size setting switch (ITV module)” (page 22) is set to “No ITV module”, the SI unit (ITV) objects will not be
displayed.
2: ITV error shows “Abnormal” in the diagnostic information of the ITV module. For more details, refer to the ITV module operation
manual. (DIY-60L00-OM002)
Note: x = Unit No.
