SMC Networks EX600-ED Series User Manual

-108-
No. DOC1045423
•SI unit (Valve) and System Diagnostics
Index
Name (Meaning)
Type
Value
50y0:0
Short circuit
UNSIGNED8
Number of Channels
50y0:01
:
50y0:80
Channel 0
:
Channel 127
Enum081C
0 = No error
1 = Error
50y1:0
Counter value exceeded
UNSIGNED8
Number of Channels
50y1:01
:
50y1:80
Channel 0
:
Channel 127
Enum081C
0 = No error
1 = Error
50y3:0
Counter value
UNSIGNED8
Number of Channels
50y2:01
:
50y2:80
Channel 0
:
Channel 127
UNSIGNED32
0 to 0xFFFFFFFF
1
50y4:0
Number of valve connections
UNSIGNED8
0 to 128
50yE:0
System error
UNSIGNED8
6
50yE:01
Valve power supply voltage outside the range
Enum081C
0 = No error
1 = Error
50yE:02
Operating power supply voltage outside the
range
Enum081C
0 = No error
1 = Error
50yE:03
Unit disconnected
Enum081C
0 = No error
1 = Error
50yE:04
Connection fault (When the power supply is
applied)
Enum081C
0 = No error
1 = Error
50yE:05
Internal memory error (When the power supply
is applied)
Enum081C
0 = No error
1 = Error
50yE:06
Internal memory error (During operation)
Enum081C
0 = No error
1 = Error
50yF:0
Error log
UNSIGNED8
31
50yF:01
:
50yF:1E
Log 0
:
Log 29
Visible
String
hhhh:mm:ss AA/BB CC
2
50yF:1F
3
Clear error log
3
Enum081D
0 = Clear
3
1: The counter value can be written only when 0 = Clear.
2: Refer to “Detail of the Log Data” (page 109).
3: Write only, and writing is only possible with 0 = Clear.
Note: y = Unit No. + 1
