Details of the Log Data
hhhh:mm:ss AA/BB CC
Time
Error code
Unit No.
Channel No.
Error code
Error code
Content
0
-
1
The short circuit has been detected.
2
The analogue input value has fallen below the setting range.
3
The analogue input value has exceeded the setting range.
4
-
5
-
6
The open circuit has been detected.
7
The analogue input or output value has exceeded the user set limit value.
8
The analogue input or output value has fallen below the user set limit value.
9
The ON/OFF counter has exceeded the user-set limit value.
10 to 15
-
16
The power supply voltage for control and input device is outside of the specification.
17
The power supply voltage for output device is outside of the specification.
18
-
19
There is a disconnection between each unit (During operation).
20
There is a connection failure between each unit (When the power supply is applied).
21
The ITV error has occurred in the ITV module.

22
Internal memory error (When the power supply is applied)
23
Internal memory error (During operation)
: ITV error shows “Abnormal” in the diagnostic information of the ITV module. For more details, refer to the ITV module operation
manual. (DIY-60L00-OM002)
