SMC Networks EX600-ED Series User Manual

-110-
No. DOC1045423
•Digital input unit, Digital output unit, Digital I/O unit (EX600-DX###,DY##,DM##)
Index
Name (Meaning)
Type
Value
50x0:0
Short circuit
UNSIGNED8
Number of Channels
50x0:01
:
50x0:18
Channel 0
:
Channel 23
Enum081C
0 = No error
1 = Error
50x1:0
Counter value exceeded
UNSIGNED8
Number of Channels
50x1:01
:
50x1:18
Channel 0
:
Channel 23
Enum081C
0 = No error
1 = Error
50x2:0
1
Open circuit in load
1
UNSIGNED8
Number of Channels
50x2:01
:
50x2:18
Channel 0
:
Channel 23
Enum081C
0 = No error
1 = Error
50x3:0
Counter value
UNSIGNED8
Number of Channels
50x3:01
:
50x3:18
Channel 0
:
Channel 23
UNSIGNED32
0 to 0xFFFFFFFF
2
1: Applicable to the open detecting digital input unit (EX600-DX#C1) and digital output.
2: The counter value can be written only when 0 = Clear.
Note: x = Unit No.
•Analogue input unit, Analogue output unit, Analogue I/O unit, Frequency count unit
(EX600-AX#, AYA, AMB, DFB)
Index
Name (Meaning)
Type
Value
50x0:0
Short circuit error
UNSIGNED8
Number of Channels
50x0:01
:
50x0:04
Channel 0
:
Channel 3
Enum081C
0 = No error
1 = Error
50x1:0

Over range error
2
UNSIGNED8
Number of Channels
50x1:01

:
50x1:04
Channel 0
2
:
Channel 3
Enum081C
0 = No error
1 = Error
50x2:0

Under range error
2
UNSIGNED8
Number of Channels
50x2:01

:
50x2:04
Channel 0
2
:
Channel 3
Enum081C
0 = No error
1 = Error
50x3:0
Exceeding the upper limit of user setting
UNSIGNED8
Number of Channels
50x3:01
:
50x3:04
Channel 0
:
Channel 3
Enum081C
0 = No error
1 = Error
50x4:0
Below the lower limit of user setting
UNSIGNED8
Number of Channels
50x4:01
:
50x4:04
Channel 0
:
Channel 3
Enum081C
0 = No error
1 = Error
: Applicable to the analogue input.
Note: x = Unit No.
