SMC Networks EX600-ED Series User Manual

-111-
No. DOC1045423
• IO-Link master unit (EX600-L#B1)
Index
Name (Meaning)
Type
Value
50x0:0
Short circuit error
UNSIGNED8
4
50x0:01
:
50x0:04
Port 1
:
Port 4
Enum081C
0 =No error
1 =Error
50x1:0
Port1-Port status
UNSIGNED8
9
50x1:01
Port status info
Enum0816
0 = NO_DEVICE
1 = DEACTIVATED
2 = PORT_DIAG
3 = PREOPERATE
4 = OPERATE
5 = DI_C/Q
6 = DO_C/Q
254 = PORT_POWER_OFF
255 = NOT_AVAILABLE
50x1:02
Port quality info
Enum0817
0 = VALID/PDOUTVALID
1 = INVALID/PDOUTVALID
2 = VALID/PDOUTINVALID
3 = INVALID/PDOUTINVALID
50x1:03
Revision ID
UNSIGNED8
0 to 0xFF
(IO-Link version of IO-Link
device)
50x1:04
Transmission rate
Enum0818
0 = NOT_DETECTED
1 = COM1
2 = COM2
3 = COM3
50x1:05
Master cycle time
UNSIGNED8
0x04 to 0xBF
( 4 to 63: 0.4 to 6.3 ms
64 to 127: 6.4 to 31.6 ms
128 to 191: 32.0 to132.8 ms)
50x1:06
Input data length
UNSIGNED8
0 to 0x20
50x1:07
Output data length
UNSIGNED8
0 to 0x20
50x1:08
Vendor ID
UNSIGNED16
1 to 0xFFFF
50x1:09
Device ID
UNSIGNED32
1 to 0xFFFFFF
50x1:0
Port2-Port status
See1 Port1-Port status
50x2:0
Port3-Port status
50x3:0
Port4-Port status
Note: x = Unit No.
