■Example of object list structure
Parameter Data and Diagnostic Data are shown with the following unit configuration as an example.
<Example>
Unit No.0
Unit No.1
ITV module and valves
End
plate
Digital input
EX600-DX#C
SI unit
EX600-MEC1
[switch setting]
4 ITV modules max.
128 valve outputs max.
4 ITV blocks
16 Valve blocks
Object
dictionary
Index
Name / Meaning
Unit No.
Parameter
Data
4000:0
Unit parameters
Unit No.0
Digital input unit
CoE detail: page 93
4002:0
Monitor counter limit
4003:0
Counter limit value (1-65000k)
4010:0
Unit parameters
Unit No.1
SI unit (ITV)
CoE detail: page 91
4011:0
ITV1 Configuration
4012:0
ITV1 Configuration
4013:0
ITV1 Configuration
4014:0
ITV1 Configuration
4020:0
Unit parameters
Unit No.1
SI unit (Valve) and System parameters
CoE detail: page 92
4022:0
Monitor counter limit
4023:0
Counter limit value (1-65535k)
4024:0
Fault mode
4025:0
Idle mode
402E:0
System parameters
Diagnostic
Data
5000:0
Short circuit
Unit No.0
Digital input unit
CoE detail: page 110
5001:0
Counter value exceeded
5003:0
Counter value
5010:0
Short circuit
Unit No.1
SI unit (ITV)
CoE detail: page 107
5011:0
ITV connection
5012:0
ITV error
5013:0
Accumulated energizing time (hour)
5020:0
Short circuit
Unit No.1
SI unit (Valve) and System Diagnostics
CoE detail: page 108
5021:0
Counter value exceeded
5023:0
Counter value
5024:0
Number of valve connections
502E:0
System error
502F:0
Error log
