Specifications
Model
EX600-ED2-#
EX600-ED3-#
EX600-ED4-#
EX600-ED5-#
Power
Power
connector
PWR IN
M12 (5-pin)
Plug
7/8 inch (5-pin)
Plug
M12 (4-pin)
Plug
M12 (4-pin)
Plug
PWR OUT
-
-
M12 (5-pin)
Socket
M12 (5-pin)
Socket
Power supply for
control and input (US1)
24 VDC ±10%,
2 A (US1)
24 VDC ±10%,
8 A (US1)
DC24 V ±10%, 4 A (US1)
Power supply for
output (US2)
24 VDC +10/-5%,
2 A (US2)
24 VDC +10/-5%,
8 A (US2)
DC24 V +10/-5%, 4 A (US2)
Environment
Enclosure
IP67 (With manifold assembled)
1
Operating temperature range
-10 to 50 °C
Storage temperature range
-20 to 60 °C
Operating humidity range
35 to 85%R.H. (No condensation)
Withstand voltage
500 VAC for 1 minute between external terminals and F.E.
Insulation resistance
500 VDC, 10 M min. between external terminals and F.E.
Standard
CE/UKCA marked,
UL (CSA)
CE/UKCA marked
Weight
2
170 g
175 g
170 g
1: All unused connectors must have a seal cap fitted to maintain IP67 rating.
2: Without End plate bracket
