SMC Networks EX600-ED Series User Manual

-62-
No. DOC1045423
■Analogue output unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Monitor short
circuit (power)
Generates error
when the short
circuit of the power
supply for the
output device is
detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Range
Sets the range of
the analogue
output device.
0..10 V
Selects the analogue
output range.
0..10 V
Channel
0..5 V
1..5 V
0..20 mA
4..20 mA
3
Data format
Sets analogue
data type of the
output data
received from the
PLC.
Offset binary
Offset binary

Unit
Signed
Magnitude
Signed magnitude
2’s complement
2’s complement
Scaled
Scale conversion type
4
Monitor upper
limit
Generates error
when the output
value exceeds the
user setting value.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

Scale setting
value upper
limit
Sets the scale
upper limit.
Generates error
when the output
value exceeds the
upper limit.
Enable
Generates an error.
Value: -32766 to 32767
Disable
Does not generate an
error.
Value: -32766 to 32767

Value:
1000
5
Monitor lower
limit
Generates error
when the output
value falls below
the user setting
value.
Enable
Generates an error.
1
Channel
Disable
Does not generate an
error.

Scale setting
value lower
limit
Sets the scale
lower limit.
Generates error
when the output
value falls below
the lower limit.
Enable
Generates an error.
Value: -32767 to 32766
Disable
Does not generate an
error.
Value: -32767 to 32766

Value: 0
6
Fault mode
2
Sets output when
communication
error is occurred.
Enable
Output will be user fault
value.
1
Channel
Disable
Output will be held last
state.

