SMC Networks EX600-ED Series User Manual

-70-
No. DOC1045423
■Temperature measurement unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Data format
Sets analogue
data type of the
input data sent to
the PLC.
Signed
Magnitude
Signed magnitude
Unit
2’s complement
2’s complement

2
Temperature
result format
Sets unit of
temperature
display.
°C
Celsius

Unit
°F
Fahrenheit
3
Number of
wires
Sets the number of
wires in resistance
temperature
detector (sensor).
2-wires
2-wire RTD
Channel
3-wires
3-wire RTD

4-wires
4-wire RTD
4
Filter
Sets analogue
input filtering time
None
None

Channel
2AVG
2 value average
4AVG
4 value average
8AVG
8 value average
