IO-Link master unit parameters
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Monitor short
circuit
If a short circuit is
detected on any of
the following, a
diagnostic will be
generated.
L+ power supply
C/Q signal
P24 power supply
Enable
Generate diagnostics
Unit
Disable
No diagnostics
2
Fault output
(IO-Link)
1
Setting for IO-Link
output process
data behavior
when EtherCAT
®
communication
errors are
detected.
Clear/
PD Out valid
All outputs are turned
OFF and
process data outputs
remain valid.
Unit
Hold
Process data outputs
remain valid.
IO-link master holds the
last process data it
received.
Clear/
PD Out invalid
All outputs are turned
OFF and
process data outputs
become invalid.
3
Fault output
(DO_C/Q)
1
Setting for digital
outputs signal
behavior when
EtherCAT
®
communication
errors are detected.
Clear
Turn OFF the digital
output.
Unit
Hold
Hold the last output
signal which IO-link
master received.
ForceON
Turn ON the digital
output.
4
Idle output
(IO-Link)
1 2
Setting for IO-Link
output process
data behavior
when EtherCAT
®
communication
idling is detected.
Clear/
PD Out valid
All outputs are turned
OFF and
process data outputs
remain valid.
Unit
Hold
Process data outputs
remain valid.
IO-link master holds the
last process data it
received.
Clear/
PD Out invalid
All outputs are turned
OFF and
process data outputs
become invalid.
