I/O Map
Allocated EX600 input and output bytes for each unit type
■Table of Allocated Input/Output bytes
Unit
Unit part number
Allocated bytes
Input
Output
SI unit
EX600-
MEC1
Switch
setting
A
Diagnostics
mode
setting
Input data only
(No Diag.)
0
0
Input data
+ System diagnosis
4
0
Input data
+ System diagnosis
+ Unit diagnosis
6
0
B
SI unit data
size setting
switch (ITV
module)
4 × ITV modules
max.
16
1
(4 bytes per 1 module)
8
1
(2 bytes per 1 module)
2 × ITV modules
max.
8
1
(4 bytes per 1 module)
4
1
(2 bytes per 1 module)
No ITV modules
0
0
C
SI unit data
size setting
switch
(Valve
output)
128 valve outputs
max.
0
16
96 valve outputs
max.
0
12
64 valve outputs
max.
0
8
32 valve outputs
max.
0
4
No valve outputs
0
0
Total Allocated bytes to SI unit
A + B + C
A+ B + C
Digital input
unit
EX600-DX#B (8 inputs)
1
0
EX600-DX#C (8 inputs)
1
0
EX600-DX#C1 (8 inputs)
(with open circuit detection)
1
0
EX600-DX#D (16 inputs)
2
0
EX600-DX#E (16 inputs)
2
0
EX600-DX#F (16 inputs)
2
0
