SMC Networks EX600-ED Series User Manual

-78-
No. DOC1045423
■Table of Allocated Input/Output bytes (continued)
Unit
Unit part number
Allocated bytes
Input
Output
Digital output unit
EX600-DY#B (8 outputs)
0
1
EX600-DY#E (16 outputs)
0
2
EX600-DY#E1 (24 outputs)
0
3
EX600-DY#F (16 outputs)
0
2
EX600-DYPG1 (4 outputs)
0
1
Digital I/O unit
EX600-DM#E (8 inputs/ 8 outputs)
1
1
EX600-DM#F (8 inputs/ 8 outputs)
1
1
Analogue input Unit
EX600-AXA (2 channels)
4
(2 bytes per channel)
0
EX600-AXB (4 channels)
8
(2 bytes per channel)
0
Analogue output
Unit
EX600-AYA (2 channels)
0
4
(2 bytes per channel)
Analogue I/O Unit
EX600-AMB (2/2 channels)
4
(2 bytes per channel)
4
(2 bytes per channel)
Temperature
measurement Unit
EX600-AT#
(4 channels)
8
(2 bytes per channel)
0
Frequency count
Unit
EX600-DFB
(4 channels)
8
(2 bytes per channel)
0
IO-Link master
Class A
EX600-LAB1
(4 ports)
22, 38, 70, or 134
2 3
22, 38, 70, or 134
2 3
IO-Link master
Class B
EX600-LBB1
(4 ports)
22, 38, 70, or 134
2 3
22, 38, 70, or 134
2 3
1: For details on ITV module input/output data, refer to the ITV module operation manual. (DIY-60L00-OM002)
When the “SI unit data size setting switch (ITV module)” (page 22) is set to “4 × ITV modules max.” or “2 × ITV modules max.”, the
data size of four or two ITV modules is added to the number of bytes allocated to the SI unit.
Regardless of whether there are more or fewer ITV modules actually connected, the size of the added data is the same as the size
of four or two ITV modules.
2: The allocated bytes of the IO-Link master can be selected by the “IO-Link master size setting switch” (page 21).
3: Each allocated bytes of the IO-Link master includes a total of 6 bytes of digital input/output data (StandardIO) and port status (PQI)
in addition to the process data of IO-Link communication.
