SMC Networks HRW D Series - System Operation

HRX-OM-K021
HRW Series
4
2.1 System Operation
Set the communicatiom mode to “DNET REMOTE”.
Figure 2-4 Set the communication mode to “DNET REMOTE”
1. Press the [SEL] key to display the
‘Menu screen 1”.
Figure 2-5 Menu screen 1
2. With the use of the arrow keys ([▲][▼]),
move the cursor to “2. REMOTE
/LOCAL” in “Menu screen 1”.
Figure 2-6 Menu screen 1
3. Press the [ENT] key.
The “Mode Selection screen” is displayed.
Figure 2-7 Mode Selection screen
＜ＭＥＮＵ＞
１．ＳＥＴＴＩＮＧ
２．ＲＥＭＯＴＥ／ＬＯＣＡＬ
３．ＩＮＩＴＩＡＬ ＳＥＴ
＜ＲＥＭＯＴＥ／ＬＯＣＡＬ＞
ＭＯＤＥ： ＬＯＣＡＬ
ＣＵＳＴＯＭ ＤＩＯ ＯＦＦ
＜ＭＥＮＵ＞
１．ＳＥＴＴＩＮＧ
２．ＲＥＭＯＴＥ／ＬＯＣＡＬ
３．ＩＮＩＴＩＡＬ ＳＥＴ
