Chapter 6 Error Message and
Troubleshooting
6.1 Error Message
The following are to be performed in the event of an error in this system.

The “ALARM” lamp comes on.

Alarm buzzer comes on.

The “Alarm Display screen” is displayed on the LCD screen.

Error signal is issued through external communication.
(See section 8.1.2 “Communication specification” in Chapter 8 on page 8-4
Appendix for details.)

This system is brought to a stop forcefully according to error types.
Figure 6-1 Error Occurrence
LCD screen
“ALARM” lamp is
ON.
Alarm Display screen (Alarm No. and alarm message)
Front
