-27-
No.PS※※-OMV0006-D
In the window comparator mode, set P1L, the lower limit of the switch operation, and P1H, the upper limit of
the switch operation, WH1 (hysteresis) and dt1 (delay time) following the instructions given on page 26.
(When reversed output is selected, the sub display (left) shows [n1L] and [n1H].)
Please refer to the "List of output modes" on page 34 for the relationship between the set values and
operation.
∗: Set OUT2 in the same way.
