SMC Networks ISE20B User Manual

-73-
No.PS※※-OMV0006-D
●Product individual parameters (continued)
Index
(dec)
Sub
index
Access
∗1
Parameter
Data
storage
∗2
Date
type
∗3
Initial value
(dec)
Remarks
0x0403
(1027)
0 R/W
dtH2
(OUT2 delay
time at ON)
Y U16
0x0000
(0)
Setting of OUT2 delay time at ON
Setting range
0x0000 ~ 0x1770
(0 ~ 6000) 0.01 s increment
0x0404
(1028)
0 R/W
dtL2
(OUT2 delay
time at OFF)
Y U16
0x0000
(0)
Setting of OUT2 delay time at OFF
Setting range
0x0000 ~ 0x1770
(0 ~ 6000) 0.01 s increment
0x0406
(1030)
0 R/W
FiL
(Digital filter)
Y U16
0x0000
(0)
Setting of digital filter
0x0000 ~ 0x0BB8
(0 ~ 3000) 0.01 s increment
0x0424
(1060)
0 R/W
FSC
(Display value
fine adjustment
ratio)
N S16
0x0000
(0)
Displayed pressure value can be
adjusted within ±5%R.D.
(-50 ~ 50) 0.1% increments
0x044C
(1100)
0 R/W
Lower level screen
Setting of
lower level
screen
Y U8 0
0: Std
1: dUAL (2 value display)
2: o1Lv (OUT1 level bar)
3: o2Lv (OUT2 level bar)
4: LinE (Line name)
5: oFF (No display)
0x044D
(1101)
0 R/W
During Std
setting
Selection of
display item
Y U8 0
Refer to Table "selection of display
items during std setting".
0x044E
(1102)
0 R/W
During 2
value setting
Selection of
display item
Left side
Y U8 0
Refer to Table "Selection of display
items during 2 value setting".
0x044F
(1103)
0 R/W
During 2
value setting
Selection of
display item
Right side
Y U8 1
