-72-
No.PS※※-OMV0006-D
●Product individual parameters (continued)
Index
(dec)
Sub
index
Access
∗1
Parameter
Data
storage
∗2
Date
type
∗3
Initial value
(dec)
Remarks
0x03FE
(1022)
0 R/W
P_2(n_2)
(Setting of
OUT2 output
set value)
Y U16
ISE20B: 0x0BB8
(3000)
ZSE20B: 0x0BB8
(3000)
ZSE20BF: 0x0FA0
(4000)
Setting of OUT2 output set value
Setting range
ISE20B: 0x0244 ~ 0x1450
(580 ~ 5200)
ZSE20B: 0x0258 ~ 0x1450
(600 ~ 5200)
ZSE20BF: 0x0384 ~ 0x13EC
(900 ~ 5100)
0x03FF
(1023)
0 R/W
H_2
(Setting of
OUT2
hysteresis)
Y U16
ISE20B: 0x04B0
(1200)
ZSE20B: 0x04B0
(1200)
ZSE20BF: 0x0C1C
(3100)
Setting of OUT2 hysteresis
Setting range
ISE20B: 0x03E8 ~ 0x15F4
(1000 ~ 5620)
ZSE20B: 0x03E8 ~ 0x15E0
(1000 ~ 5600)
ZSE20BF: 0x0BB8 ~ 0x1C20
(3000 ~ 7200)
0x0400
(1024)
0 R/W
P2L(n2L)
(Setting of
OUT2 output
set value_
Lower limit of
window
comparator)
Y U16
ISE20B: 0x0898
(2200)
ZSE20B: 0x0898
(2200)
ZSE20BF: 0x0E10
(3600)
Setting of OUT2 output set value
(lower limit of window comparator)
Setting range
ISE20B: 0x0244 ~ 0x1450
(580 ~ 5200)
ZSE20B: 0x0258 ~ 0x1450
(600 ~ 5200)
ZSE20BF: 0x0384 ~ 0x13EC
(900 ~ 5100)
0x0401
(1025)
0 R/W
P2H(n2H)
(Setting of
OUT2 output
set value_
Upper limit of
window
comparator)
Y U16
ISE20B: 0x0D48
(3400)
ZSE20B: 0x0D48
(3400)
ZSE20BF: 0x1068
(4200)
Setting of OUT2 output set value
(upper limit of window comparator)
Setting range
ISE20B: 0x0244 ~ 0x1450
(580 ~ 5200)
ZSE20B: 0x0258 ~ 0x1450
(600 ~ 5200)
ZSE20BF: 0x0384 ~ 0x13EC
(900 ~ 5100)
0x0402
(1026)
0 R/W
WH2
(Setting of
OUT2
hysteresis_
Window
comparator
hysteresis)
Y U16
ISE20B: 0x0578
(1400)
ZSE20B: 0x0578
(1400)
ZSE20BF: 0x0C80
(3200)
Setting of OUT2 hysteresis
(window comparator hysteresis)
Setting range
ISE20B: 0x03E8 ~ 0x0CEE
(1000 ~ 3310)
ZSE20B: 0x03E8 ~ 0x0CE4
(1000 ~ 3300)
ZSE20BF: 0x0BB8 ~ 0x13EC
(3000 ~ 5100)
