SMC Networks ISE20B User Manual

-90-
No.PS※※-OMV0006-D
Product No.
ZSE20B
(Vacuum pressure)
ZSE20BF
(Compound pressure)
ISE20B
(Positive pressure)
Environment
Enclosure
IP65
Withstand voltage
1000 VAC for 1 minute between terminals and housing
Insulation resistance 50 MΩ or more between terminals and housing (with 500 VDC megger)
Ambient temperature range
Operation: -5 to 50
o
C, Storage: -10 to 60
o
C
(No condensation or freezing)
Operating humidity range
Operation, Storage: 35 to 85%RH (No condensation)
Standard
CE marked (EMC directive, RoHS directive)
Length of lead wire with connector
2 m
∗1: Value without digital filter (at 0 ms).
∗2: If the applied pressure fluctuates around the set value, the hysteresis must be set to a value more than the amount of fluctuation or
chattering will occur.
∗3: This setting is only available for models with the units selection function. Only MPa or kPa is available for models without this function.
∗4: The response time indicates when the set value is 90% in relation to the step input.
∗5: Any products with tiny scratches, smears, or variations in the display color or brightness, which does not affect the performance of the
product, are verified as conforming products.
