SMC Networks ISE20B User Manual

-91-
No.PS※※-OMV0006-D
○Piping/weight specifications
Product No.
M5
01
N01
Port size
M5 x 0.8
R1/8
NPT1/8
Materials in
f
luid contact
part
Pressure-sensing part
Silicon
Piping port (Common)
PBT, CB156, heat resistant PPS, O-ring: HNBR
Piping port -
C3604 (Electroless nickel plating), SUS304,
NBR
Weight
Body 24 g 34 g 36 g
Lead wire with connector +39 g
○Cable specifications
Conductor area
0.15 mm
2
(AWG26)
Insulator
Outside diameter 1.0 mm
Color Brown, Blue, Black, White, Gray (5 core)
Sheath
Finished outside diameter φ3.5
○Communication specifications (During IO-Link mode)
IO-Link type
Device
IO-Link version
V1.1
Communication speed
COM2 (38.4 kbps)
Configuration file
IODD file
∗6
Min. cycle time
2.3 ms
Process data length
Input Data: 2 byte, Output Data: 0 byte
On request data communication
Available
Data storage function
Available
Event function
Available
Vendor ID
131 (0x0083)
Device ID
ISE20B-L(-M)-∗: 334 (0x014E)
ISE20B-L-P-∗: 335 (0x014F)
ZSE20B-L(-M)-∗: 336 (0x0150)
ZSE20B-L-P-∗: 337 (0x0151)
ZSE20BF-L(-M)-∗: 338 (0x0152)
ZSE20BF-L-P-∗: 339 (0x0153)
∗6: The configuration file can be downloaded from the SMC website, https://www.smcworld.com
