SMC Networks ZSE20 Series User Manual

3020
20 30
M5 x 0.8
Thread depth 3.5
A
15.2
4 x Ø 2.6
Depth 7 or less
Atmospheric vent port
4 x Ø 2.6
Depth 7 or less
Atmospheric vent port
25
25 51.5
51.5
Lead wire with connector
Lead wire with connector
For 20
For 20A/20B
7.2
N01
M5
01
Dimensions
M5 female thread
R1/8
NPT1/8
Piping specifi cation Port size
A
01
R1/8 Width across fl ats 10
N01
NPT1/8 Width across fl ats 12
ZSE20첸(F)
ISE20첸
Piping specifi cation
If there is a possibility that the atmospheric vent port of the switch
will be exposed to water or dust, insert a tube into the atmospheric
vent port and route the other end of the tube to a safe place away
from water or dust. (Z/ISE20B)
∗ For tubing, please use the SMC TU0425 (polyurethane, O.D. Ø
4, I.D. Ø 2.5) for the pressure switch.
15
ZSE20
첸
(
F
)
/ISE20
첸
Series
