SME AC-M1 User Manual

ACM1_TAU_UserManual_En
Page 10 of 35
SME s.p.a. Via della Tecnica 40 Z.I.
36071 ARZIGNANO (VI) ITALY
Phone +39 0444 470511 - Fax +39 0444 451803
info@grupposme.com - www.grupposme.com
K2 connector pin-out for AC-M1 SPECIFICATIONS
Pin
Name
I/O
Specification
Function
1
+5V OUT
Supply Output
5V+/-5%, 200mAmax
5V supply
2
DIGITAL IN 9
Digital Input
20mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
3
DIGITAL IN 10
Digital Input
20mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
4
ENCODER 1 B
Peripheral Input
20mA pull-up, VL<=1V, VH>=3,5V
Quad encoder channel B
5
ENCODER 1 A
Peripheral Input
20mA pull-up, VL<=1V, VH>=3,5V
Quad encoder channel A
6
DIGITAL IN 11
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
7
DIGITAL IN 12
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
8
DIGITAL IN 13
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
9
I/O GROUND
-
-
Negative logic supply
10
MOTOR
THERMAL
PROBE 1
Analog Input
Pull-up
Motor temperature probe
11
MOTOR
THERMAL
PROBE 2
Analog Input
Pull-up
TO BE ASSIGNED
12
ANALOG IN 1
Analog Input
0/12V pull-down
TO BE ASSIGNED
13
ANALOG IN 2
Analog Input
0/12V pull-down
TO BE ASSIGNED
14
DIGITAL IN 14
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
15
DIGITAL IN 15
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
16
DIGITAL IN 16
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
17
DIGITAL IN 17
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
18
DIGITAL IN 18
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
19
ANALOG IN 3
Analog Input
0/12V pull-down
TO BE ASSIGNED
20
ANALOG IN 4
Analog Input
0/12V pull-down
TO BE ASSIGNED
21
ANALOG IN 5
Analog Input
0/12V pull-down
TO BE ASSIGNED
22
ANALOG IN 6
Analog Input
0/12V pull-down
TO BE ASSIGNED
23
DIGITAL IN 19
Digital Input
4mA pull-up, VL<=1V, VH>=3,5V
TO BE ASSIGNED
