ACX1_TAU_SYNC_UserManual_En
Page 18 of 37
SME S.p.A. Via della Tecnica 40 Z.I.
36071 ARZIGNANO (VI) ITALY
Phone +39 0444 470511 - Fax +39 0444 451803
sales@sme-group.com - www.sme-group.com
4. Additional heatsink could be necessary to meet the desired continuous ratings. The heat
sink material and system should be sized on the performance requirement of the machine.
We recommend ambient temperature air to be directed over the heatsink fins to maintain
heatsink temperature below 75 °C.
5. In systems where either ventilation is poor, or heat exchange is difficult, forced air
ventilation should be used.
Clearances
For all AC-X1 models 50 mm clearances in front of and behind the AC-X1 are required for airflow;
50 mm clearance above the AC-X1 is required for installation/removal of interface connectors and
wiring.
