22.
Remove the brackets and mark a
distance of 8 mm from the outer edge
of the door where the nail must be fitted
(K).
23. Place the small square on the guide
again and fix it with the screws
supplied.
24. Align the kitchen furniture door and the
appliance door by adjusting the part
(Hb).
25.
Press the part (Hd) on the part (Hb).
Do a final check to make sure that:
• All screws are tightened.
• The sealing strip is attached tightly to the
cabinet.
• The door opens and closes correctly.
TECHNICAL INFORMATION
Technical data
Height mm 1446
Width mm 560
Depth mm 550
Rising time Hours 20
Voltage Volts 230 - 240
16
