242221
1. Front panel
2. Detergent dispenser
3. Door (depending on the model)
4. Filter lid
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Mains power cable
• Max. load: 6 kg / 7 kg
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Depth with door open: 106 cm
Weight (net): 90 kg
Nominal voltage: 230 V, 50 Hz
Power: 2300 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
• Max. load: 4,5 kg
Dimensions slim aparat (w x d x h):
600 mm x 440 mm x 850 mm
Depth with door open: 88 cm
Weight (net): 76 kg
Nominal voltage: 2000 W
3
Description of washing machine
Technical information
(depending on the model)
