INSTALLATION - 3991477A872/A
e
The nozzles not provided are available at Authorised Service Centres.
70 cm models:
6 LPG G30/31 - 37 mbar AUX SR RR UR
Rated heating capacity (kW) 1.10 1.80 2.60 3.50
Nozzle diameter (1/100 mm) 48 60 73 82
Reduced flow rate (W) 450 500 800 1600
Primary air (mm) 1.5 1.5 1.5 2
Rated flow rate G30 (g/h) 80 131 189 254
Rated flow rate G31 (g/h) 79 129 186 250
7 Town gas G110 – 8 mbar AUX SR RR UR
Rated heating capacity (kW) 1.10 1.80 2.60 3.50
Nozzle diameter (1/100 mm) 132 165 210 270
Reduced flow rate (W) 400 500 750 1400
Primary air (mm) 0.5 1 0.5 1
1 Natural Gas G20 - 20 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 1.10 3.10
Nozzle diameter (1/100 mm) 73 95 115 140 73 123
Reduced flow rate (W) 400 500 750 1800 400 1400
Primary air (mm) 11.51 11.51
2 Natural Gas G20 - 25 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 1.10 3.10
Nozzle diameter (1/100 mm) 73 87 110 132 73 120
Reduced flow rate (W) 400 500 750 1800 400 1400
Primary air (mm) 11111.51.5
3 Natural Gas G25.1 - 25 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 1.0 3.20
Nozzle diameter (1/100 mm) 76 98 123 150 76 135
Reduced flow rate (W) 400 500 750 1800 400 1400
Primary air (mm) 110.5111
4 Natural Gas G2.350 - 13 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 1.10 3.10
Nozzle diameter (1/100 mm) 100 126 160 200 48 85
Reduced flow rate (W) 400 500 750 1800 400 1400
Primary air (mm) 1 1 1 1.5 1.5 10
5 LPG G30/31 - 30/37 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 1.10 3.10
Nozzle diameter (1/100 mm) 48 62 76 95 48 85
Reduced flow rate (W) 400 500 750 1800 400 1400
Primary air (mm) 1.5 1.5 1.5 3 1.5 10
Rated flow rate G30 (g/h) 80 131 189 291 80 225
Rated flow rate G31 (g/h) 79 129 186 286 79 221
6 LPG G30/31 - 37 mbar AUX SR RR UR* UR2 int. UR2 ext.
Rated heating capacity (kW) 1.10 1.80 2.60 4.0 0.90 3.20
Nozzle diameter (1/100 mm) 48 60 73 89 45 80
Reduced flow rate (W) 450 500 800 1850 450 1400
Primary air (mm) 1.5 1.5 1.5 3 2 5
Rated flow rate G30 (g/h) 80 131 189 291 65 233
Rated flow rate G31 (g/h) 79 129 186 286 64 229
