Instructions for the installer
6
2. INSTALLATION
2.1 Electrical connection
Make sure that the voltage and capacity of the power supply line
conform to the data shown on the plate on the oven door frame.
Do not remove this plate for any reason.
It is obligatory for the electrical system to be earthed according to the
methods required by safety rules.
If a plug and socket connection is being used make sure that the plug
and socket are compatible. Avoid use of adapters and shunts as these
could cause overheating and risk of burns.
If the appliance is connected to the power supply network in a
permanent manner, install a multipolar cut-out device on the line, with
contact opening distance equal to or greater than 3 mm located near the
oven and in an easily reachable position.
For operation on 230V
∼
: use a H05RR-F /
H05RN-F type three-core cable (3 x 1.5
mm
2
).
The cable end to be connected to the
appliance must be provided with an earth
wire (yellow-green) at least 20 mm longer.
The manufacturer declines all responsibility for damage to persons
or things caused by non-observance of the above prescriptions or by
interference with any part of the appliance.
