4. Attach the stripes to the rabbets. Do
not extend the stripes. Do not bond
ends of stripes one over another.
After you assemble the hob, seal the
remaining gap between glass ceramic and
the worktop with silicone. Make sure the
silicone does not get under the glass
ceramic.
Assembly
If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.
On-top installation
1.
R 5mm
min.
55mm
560
+1
mm
490
+1
mm
2.
3.
19
