On-top installation
1.
R 5mm
min.
55mm
560
+1
mm
490
+1
mm
2.
3.
min.
28 mm
4.
min.
12 mm
Integrated installation
1.
514
+1
mm
560
+1
mm
490
+1
mm
604
+1
mm
R5 mm
R5 mm
7 mm
min.55mm
2.
min.
38 mm
8
