If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.
You can instal a separation
panel but it is not mandatory.
TECHNICAL DATA
Rating plate
Model SI5632D PNC 949 492 320 00
Typ 61 B3A 02 AD 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.2 kW Made in Romania
Ser.Nr. ................. 7.2 kW
SMEG
Cooking zones specification
Cooking zone Nominal pow‐
er (maximum
heat setting)
[W]
Power func‐
tion [W]
Power func‐
tion maximum
duration [min]
Cookware di‐
ameter [mm]
Left front 2300 3700 10 180 - 210
Left rear 1400 2500 4 125 - 145
Right front 1800
3500
2800
3700
10
5
145 - 245
245 - 280
The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the cookware.
For optimal cooking results use cookware
no larger than the diameter in the table.
17
