5.8.1 Power supply setting
The device can operate either with single-phase or three-phase power supply. However, the deliverable
output current strictly depends on the type of power supply (in single phase there is a considerable derating).
For a correct operation, it is necessary to set the type of power supply, by connecting or not a jumper between
pin 1 and 2 of the CTR connector. The following table indicates the available statuses:
Connector type: Phoenix Contact FMC 1,5/7-ST-3,5 (1952319)
Order code: KF101050
Features Conductors cross section * **
Connection in accordance with EN-VDE Solid min. 0,2 mm²
Rated voltage 160 V Solid max. 1,5 mm²
Rated current 8 A
Stranded min. 0,2 mm²
Stranded max. 1,5 mm²
Insulating material PA
Stranded, with ferrule without plastic
sleeve min.
0,25 mm²
Inflammability class according to
UL 94
V0
Stranded, with ferrule without plastic
sleeve max.
1,5 mm²
Stripping length 10 mm
Stranded, with ferrule with plastic sleeve
min.
0,25 mm²
Screwdriver to be used for open-
ing the connections
0,6 x 3,5 mm
Stranded, with ferrule with plastic sleeve
max.
0,75 mm²
AWG according to UL / CUL min 24
AWG according to UL / CUL max 16
*= Use 60 °C / 75 °C wires only
**= Use Copper Conductors only
Jumper Setting Notes
Absent Single-phase
Check of phase loss not active.
Low current limit
Present Three-phase
Check of phase loss active.
High current limit
