KITS, PARTS & ACCESSORIES CONTINUED
3A 182485 HANDLE, PUMP
3B 182711 HANDLE LOCKING COLLAR
3C 182704 SPRING (2)
3D 182484 4-TAB CLAMP
3E 182714 TANK COVER
3F 182712 FLAT WASHER
3G 182713 RETAINING RING
3H 182519 O-RING 105mm x 5.7mm, V
3J 182715 PUMP ROD
3K 182706 VALVE SEAT
3L 182523 O-RING 30mm x 4mm, V
3M 182707 PISTON PLATE
3N 182708 LOCKNUT
3P 182524 O-RING 46mm x 3.5mm,V
3R 182710 PUMP BARREL
3S 182535 CHECK VALVE, PUMP, V
KIT #3 182522 PUMP Viton
(Brown O-rings & Gasket)
KEY# PART# DESCRIPTION
5 182677 SHOULDER HARNESS
6 182567 NOZZLE, ADJUSTABLE, BRASS
7
-1 182578 FLAT FAN TIP, BRASS, .2 GPM-65°
-2 176042 FLAT FAN TIP, BRASS, .2 GPM-80°
-3 176116 FLAT FAN TIP, BRASS, .4 GPM-80°
-4 176171 FLAT FAN TIP, BRASS, .5 GPM-80°
-5 182577 FLAT FAN TIP, BRASS, .5 GPM-95°
-6 182576 FLAT FAN TIP, BRASS, 1 GPM-110°
8
-1 182795 NOZZLE, #4 GREEN POLY, .07 GPM-80°
-2 182796 NOZZLE, #6 RED POLY, .10 GPM-80°
-3 182797 NOZZLE, #10 BLACK POLY, .10 GPM-80°
-4 182784 NOZZLE, #8 GRAY POLY, .13 GPM-80°
-5 182798 NOZZLE, #12 BROWN POLY, .20 GPM-80°
-6 182785 NOZZLE, #8 BRASS CONICAL
9 183300 SHUT-OFF
A 182519 O-RING 105mm x 5.7mm, VITON
B 182535 CHECK VALVE, PUMP VITON
C 182523 O-RING 30mm x 4mm, VITON
D 182524 O-RING, 46mm x 3.5mm, VITON
KIT #4 182644 PUMP GASKETS VITON
(Brown O-rings & Gasket)
KIT #10 183525 SHUT-OFF SERVICE KIT
10A 182474 O-RING, 1.9mm x 4.2mm, VITON
10B 183304 VALVE STEM, BRASS
10C 182476 SEAL, VALVE, VITON
10D 183305 VALVE BASE, BRASS
10E 183306 SPRING, VALVE
10F 183303 CAP, VALVE
10G 182468 O-RING, 2.4mm x 11.2mm, VITON
10H 182467 FILTER
KEY# PART# DESCRIPTION
182521 3.5 GALLON TANK, VITON
(INCLUDES KEY #2)
2
182678 VITON PRV ASSEMBLY
1
KEY# PART# DESCRIPTION
11
-1 183294 24” WAND ASSEMBLY, BRASS
-2 183296 NUT, BRASS CAP
12 183381 HOSE ASSEMBLY
