5. MAXIMUM TORQUE screen is displayed next. MAXIMUM TORQUE is torque value above which
red progress lights turn on. Initial MAXIMUM TORQUE value will be MINIMUM TORQUE plus 4%.
Maximum torque value can be set greater than MINIMUM TORQUE value to 10% above wrench
maximum range by pressing UP   /DOWN   buttons. Once desired value has been set, press
ENTER   button.
6. BATCH COUNT screen is displayed next. Default value is zero. Batch count range is 0 to 99. Press
UP   /DOWN   buttons to increment/decrement batch count. Mode Count increments each
time target torque is reached if a batch count of zero is entered. Mode Count decrements if a
non-zero batch count is entered and resets to batch count value when count reaches zero. Once
desired value has been set, press ENTER   button.
7. PSET target screen is displayed labeled with next available PSET number from 01 to 10.
8. To enter additional torque presets, repeatedly press ENTER   button until target torque screen
is displayed and repeat steps above.
Adding an Angle Preset
1. From target angle screen, press and hold UNITS U button for 3 seconds.
2. ADD PRESET confirmation screen is displayed. Highlight YES menu selection using UP   /DOWN
  buttons then press ENTER   button. NO menu selection returns to main menu without adding
a PSET.
3. MINIMUM ANGLE screen is displayed. MINIMUM ANGLE is target value at which green progress
lights, audible alert and vibrator turn on. Initial MINIMUM ANGLE value is value from target angle
screen. MINIMUM ANGLE can be set from 0 to 360° by pressing UP   /DOWN   buttons. Once
desired target angle value has been set, press ENTER   button.
4. MAXIMUM ANGLE screen is displayed next. MAXIMUM ANGLE is angle value above which red
progress lights turn on. Initial MAXIMUM ANGLE value will be MINIMUM ANGLE plus 4%.
Maximum angle value can be set to any value greater than MINIMUM ANGLE by pressing
UP   /DOWN   buttons. Once desired value has been set, press ENTER   button.
5. BATCH COUNT screen is displayed next. Default value is zero. Batch count range is 0 to 99. Press
UP   /DOWN  buttons to increment/decrement batch count. Mode Count increments each
time target angle is reached if a batch count of zero is entered. Mode Count decrements if a non-
zero batch count is entered and resets to batch count value when count reaches zero. Once
desired value has been set, press ENTER   button.
6. PSET target screen is displayed labeled with next available PSET number from 01 to 10.
7. To enter additional angle presets, repeatedly press ENTER   button until target angle screen is
displayed and repeat steps above.
ENTER button
UP/DOWN buttons
ENTER
button
UNIT
button
held
Target Torque Screen
UP/DOWN buttons
UP/DOWN buttons
ENTER
button
ENTER
button
UP/DOWN buttons
ENTER button
Preset Torque Screen
00
100.0 IN-LB
ADD PRESET
YES
NO
ADD PRESET
YES
NO
MINIMUM TORQUE
100.0 IN-LB
MAXIMUM TORQUE
104.0 IN-LB
BATCH COUNT
3
PSET 01 03
100.0 IN-LB
