13
EEBC302A Operating Instructions
1. Attach handle to charger with four screws provided.
2. Attach crossbar to handle with two screws provided.
3. Attach foot to base with two hex head screws provided.
4. Slide wheel onto axle with hub toward charger, then slide
axle through charger base.
5. Place remaining wheel on axle and tap retainer nuts onto
axle.
Maintenance
• Unplug power cord from outlet before cleaning or
maintaining charger. Turning off controls will not
reduce this risk.
• Read, understand and follow Safety Information in
the front of this manual.
Clean the case using a mild detergent. Do not allow liquid to
drip into the case.
Do not remove the case to perform routine maintenance. Worn
parts can compromise safety and charger performance.
Replace parts as needed. For service, contact your sales
representative.
Parts List
Description Part Number
Rectifier Assembly ...................................... BC4200-2000R
Transformer Assembly ................................ EAT0003K11AR
Fan Blade ................................................................ 2-1268
Fan Motor ............................................................ 2-10166-1
DC Leads with Clamps .................................. BC4200-100R
DC Circuit Breaker .................................................. 2-15366
AC Circuit Breaker .................................................. 2-10266
Ammeter .................................................................... 4-280
Power Cord .............................................................. 6-2821
Range Switch ............................................................ 2-9958
Charge Timer .......................................................... 2-14866
Knob, Charge Timer .................................................. 8-8230
Foot with 4 Screws ...................................... EAK0073K27A
Wheel Kit ...................................................... EAK0073K26A
Includes 2 wheels, 2 push nuts and axle
